Monitor CO2 in duct work
- Measures carbon dioxide from 0 to 2,000 PPM
- Accurate to ±30 PPM
- Set high and low limits by programming the Sensaphone
- Sensaphone will go into alarm when carbon dioxide level exceeds limit
- Weatherproof enclosure allows monitoring in duct work
The Sensaphone Carbon Dioxide sensor will detect levels of Carbon Dioxide from 0-2,000 ppm. Used with any Sensaphone that will accept a 4-20mA input signal, the device will provide real time data and will cause your Sensaphone to activate an alarm when the CO2 level reaches a set threshold. The sensor is specifically designed to be mounted in a return air duct.
Technical Specifications
Sensor Coverage Area: 100 m2 (1000 ft2) typical
Accuracy: ±30 PPM + 3% of reading with Auto Cal on
Measuring Range: 0-2,000ppm
Response Time: <2 minutes for 90% step change typical
Operating Temperature Range: 32° to 122°F | 0° to 50°C
Dimensions: 5.7 x 3.95 x 2.5” | 145 x 100 x 63mm
Sensor Series: 4-20mA
