Product Description
Monitor humidity in harsh locations
- Monitors humidity levels from 0% to 100% RH
- Weatherproof enclosure
- Easy installation into tight spaces with compact NEMA 3S housing
This humidity transmitter can be used with Sensaphone models that accept a 4-20mA signal to detect humidity levels. The device will cause your Sensaphone to activate an alarm when the humidity level reaches a set threshold. With a range of 0% to 100% RH level, the sensor causes an alarm when the humidity exceeds or falls below the set limit. The sensor is mounted in a weatherproof enclosure to allow for mounting in harsh locations. The sensor will need a 24VDC power supply to operate (Part # FGD-0070)
Technical Specifications
Humidity Level Monitoring Range: 0 to 100% RH
Accuracy: 3% 20 to 80% RH, 4% @ 10-20%, 80 to 90%
Dimensions: 2.75 x 4.56 x 1.42" | 70 x 116 x 36mm
Sensor Response Time: 15 seconds typical
Drift: <1% RH/year
Operating Temperature Range: -40° to 140°F | -40° to 60°C
Operating Humidity: 0 to 95% RH non-condensing
Weight: 0.3oz. | 8.5g
