Product Description
Monitor the output of a 4-20mA transducer
- Interfaces IMS system with any 4-20mA transducer
- Set high and low limits of transducer by programming the Sensaphone
- Sensaphone will go into alarm when transducer level exceeds limit
- Required RJ45 patch cable powers and connects interface to Sensaphone
The IMS 4-20mA Interface is used exclusively with the Sensaphone IMS system system to interface with any third party transducer that outputs a 4-20mA signal. The interface will measure and provide real time values to to the IMS system. When the level falls outside of the IMS’s programmed high or low limit, the user will receive an alarm which displays or reads the current value. The connection from the interface to the IMS system can use an existing CAT5 network wiring infrastructure, which allows it to be installed in locations away from the IMS host device.
Technical Specifications
Operating Temperature: 32° to 122°F | 0° to 50°C
Current Limit: 50mA
Connection: RJ45
Housing: Plastic
Dimensions: 3.3 x 4.2 x 1.3" | 84 x 107 x 33mm
Sensor Series: IMS Solution
