Product Description
Detect unauthorized entry or intrusion
- Detects when a door or window is opened or closed
- Sends Sensaphone into alarm when door or window condition has changed
- Easily mounted with included hardware
- Required RJ45 patch cable powers and connects sensor to Sensaphone
- May be mounted either on a wall or rest on the floor - switch is mounted to doors or windows you wish to monitor.
The IMS Magnetic Reed Door and Window Switch is used exclusively with the Sensaphone IMS system system to monitor for any unauthorized entry or intrusion. When the door or window is opened or closed, the sensor will trigger the Sensaphone to go into alarm. The switch is usually installed to function in a normally closed position when the door or window is closed. The complete Magnetic Reed Switch assembly comes in two main parts: a magnet in a plastic housing, and a switch with screw terminals in another, separate plastic housing. It mounts to the door or window with the included hardware. The connection from the sensor to the IMS system can use an existing CAT5 network wiring infrastructure, which powers the sensor and allows it to be installed in locations away from the IMS host device.
Technical Specifications
Bridge Input: Normally Open or Normally Closed Contact
Source/Sense Voltage: 14VDC
Connection: RJ45
Housing: Plastic
Dimensions: 2.1 x 1.3 x .6" | 53 x 33 x 15mm
Sensor Series: IMS Solution
Downloads
IMS Solution Magnetic Reed Door and Window Switch Sales Brochure
