Product Description
Monitor Dry Contacts with your IMS-4000E system
- Allows users to monitor up to 8 dry contact inputs
- Monitor equipment such as alarm panels, UPS alarms, PDU alarms, automatic transfer switches or security systems
- Works in conjunction with Sensaphone IMS-4000 Host
- Battery backup in the event of a power failure
- Can be set to alarm on power failure
The IMS-4000 Dry Contact Node provides eight dry contact inputs (normally open/normally closed) and works in conjunction with the IMS Host. When the contact switches position the Expansion Node will communicate the change back to the IMS system and users will receive an alarm via phone, text message or email. It is ideal for monitoring the alarm outputs of devices such as a UPS, power distribution unit, fire alarm panel, automatic transfer switch or security system. The device communicates with the IMS-4000E Host via its Ethernet connection. The unit uses four AA rechargeable NiMH batteries (included) for power backup in the event of a power failure. Both main power and battery charge are monitored and can be programmed to trip alarms as well. The unit comes in a black plastic enclosure with tabs for wall mounting. Rubber feet are also included for placement on a shelf/desktop.
Technical Specifications
Number of Inputs: 8
Input Type: Dry Contact, Normally Open or Normally Closed (configurable for each input)
Internal Monitoring: AC Power, Backup Battery
Ethernet: 10/100 Base-T, 10/100Mbps (supports Sensaphone Locator software)
Serial Port: 9600Bps for network configuration
Local Indicators: Power LED, Ethernet LEDs
Operating Temperature: 32° to 122°F (0° to 50°C)
Operating Humidity: 5 - 90% RH non-condensing
Power Consumption: 2.5W
Power Requirements: IMS-4010: 120VAC 60Hz/9VDC 300mA (min) Power Supply
IMS-4010-INT: 90-260VAC 50/60Hz 300mA (min) Multiplug Power Supply
Battery Backup: Four AA NiMH Rechargeable Battery, 2000mAHr or higher (included)
Dimensions: 7.3 x 5.5 x 1.5" | 18.5 x 14 x 3.8 cm
Weight: 2lbs. | .9kg
